TPU Color Wrap Film for Premium Vehicle Color Change
Features:
- TPU Film Construction – Flexible TPU face film designed for premium automotive wrapping.
- High Stretchability – Representative elongation at break of 130–180%.
- High-Gloss Appearance – Representative 60° gloss of 85–95 GU.
- Self-Healing Surface Performance – Helps recover from light surface marks under suitable conditions.
- Added Surface Protection – TPU film provides an additional protective surface while changing the vehicle appearance.
Applications:
- Full vehicle color change
- Partial vehicle wrapping
- Luxury vehicle customization
- Vehicle protection and styling
- Curved automotive body panels
Representative Technical Specification
| Model | Face Material | Face Film Thickness | Adhesive Layer Thickness | Release Liner Thickness |
Coating Elongation at Break | 60° Gloss | Loop Tack Adhesion |
| VGB1001 | TPU | 150μm | 33±3μm | 75μm |
130-180% | 85-95 GU | 10-20 N/in |
*The specifications above represent one available TPU color wrap film construction. Film thickness, adhesive structure, release liner and other specifications may vary by product grade and color series.
Why TPU for Vehicle Wrapping?
TPU and PVC are both used for automotive color-change films, but they have different material characteristics.
TPU is valued for its:
- High flexibility
- High elongation
- Soft and conformable film structure
- Premium surface appearance
- Self-healing capability
- Durable surface performance
These properties make TPU Color Wrap Film particularly suitable for higher-end vehicle customization projects.
Actual performance depends on the complete film construction, adhesive system, installation conditions and vehicle geometry.
How to Choose TPU Color Wrap Film
Choose the film according to the vehicle geometry, appearance requirements and expected application performance.
1. Confirm the Coverage Area
Determine whether the project requires:
- Accent wrap
- Partial vehicle wrap
- Full vehicle color change
2. Evaluate Vehicle Geometry
TPU film can be considered for:
- Flat panels
- Gentle curves
- Compound curves
- Bumpers
- Mirrors
- Complex vehicle contours
The more demanding the geometry, the more important flexibility and elongation become.
3. Confirm the Required Appearance
Choose the required color and finish according to the final vehicle styling direction.
For high-gloss applications, representative TPU grades can provide a 60° gloss value of 85–95 GU.
4. Consider Stretchability
One representative TPU construction has a coating elongation at break of:
130–180%
This provides a useful technical reference when evaluating the film for curved vehicle surfaces.
5. Confirm Adhesive Performance
One representative grade has a loop tack adhesion of:
10–20 N/in
Adhesive performance should be evaluated together with vehicle surface condition, application temperature and installation method.
6. Test Before Bulk Application
Sample installation on the actual vehicle surface is recommended before bulk purchasing or large-scale application.
Self-Healing Surface Performance
TPU materials can provide self-healing behavior for light surface marks under suitable conditions.
This feature helps maintain the visual appearance of the wrap surface during normal vehicle use.
Self-healing performance can depend on:
- Surface temperature
- Scratch depth
- Environmental conditions
- Film construction
- Product grade
Deep scratches, cuts or damage through the film should not be expected to recover through self-healing.
FAQ
What is TPU Color Wrap Film?
What are the main advantages of TPU Color Wrap Film?
What is the difference between TPU and PVC Color Wrap Vinyl?
Is TPU Color Wrap Film suitable for complex curves?
What is the gloss level of TPU Color Wrap Film?
Does TPU Color Wrap Film have self-healing performance?
Is TPU Color Wrap Film a Paint Protection Film?
Can TPU Color Wrap Film be used for full vehicle wrapping?
